Patents |
| a
no of patents pending also...... |
|
Business
Expansion |
|
|
|
|
 Motors
and controls
PMSM, BLDC,
SRM
PMSM,ACIM,BLDC,DC,
Stepper and SRM |
|
processing
Ethernet
camera ,Scanning camera
3D Imaging
system. |
|
Embedded
products:
Class-D
Public address amplifier, audio visual, sinewave inverter. |
|
Electro
mechanical
Flying
car/UAV/VTOL Toy, Electric bike,
Submersible
pump
|
|
Vibration
system
DSP based
vibration controller with class D amplifier. |
|
Research
on gravity
magnetism
Paper published in
"Gravitation & Cosmology" proceedings,ICGA-5, 2001 .
|
|
| |
|
|
 |
|
|
| |
R & D ACTIVITIES
|
 |
|
| |
 |
Research & Development of Indigenous Technology and Manufacturing of Prototypes.
|
|
|
Design & Development of new products/processes.
Embedded PC.
|
|
|
Modification and Upgradation of existing products.
|
|
|
Research & Development of new technology -
Gravity Motor.
|
 S.K. Dynamics Pvt. Ltd. (SKD) came into existence in 1992 with the object of carrying out Research and Development work at an advanced level with stress on multidisciplinary approach in the field of Electronics and Electromechanical Engineering including manufacturing. S.K. Dynamics was founded by Mr. Rakesh Goel to give undivided attention to R&D efforts in diverse field.
Prior to the incorporation of SKD Mr. Goel was associated with Saraswati Dynamics Pvt. Ltd. (SDPL) as a Technical Director since its inception in 1974 and was responsible for all technical development in the company including the development of Vibration and Environmental test systems.
SKD is actively engaged in Research and Development including manufacturing of prototypes. It is equipped with most modern facilities and powered by a team of professionally qualified engineers. The core strengths of the company are quality and commitments in the developments of new technologies to ensure highly reliable products. It enjoys the reputation of a dependable technology driven company maintaining leading edge technology for its products.
  Major
resources of the company are earned
from Short Term Projects
like PMSM, SRM, ACIM motors and their controllers for
Industrial and commercial applications. Equal emphasis is
given on the Long Term Projects to benefit the mankind with much better
technology for global applications keeping in mind to work towards Environment
Friendly Technology [for a Green Earth].
PRODUCTS DEVELOPED AND MANUFACTURED
[In last 20 years]
TRANSDUCERS / SENSORS
|
|
Velocity Pickup / Geophone
|
|
|
Variable Reluctance Accelerometer
|
|
|
LVDT
|
|
|
Tachometer
|
|
|
Strain Gauge based Earth Pressure Cell and Pore Pressure Transducers
|
|
|
Strain gauge based Inclinometer
|
|
|
Vibrating Wire Pore Pressure Transducer
|
|
|
Vibrating Wire Inclinometer
|
|
|
Piezo Electric Accelerometers
|
|
|
Piezo Electric Accelerometer with built in charge amplifier
|
|
|
Incremental Rotary Optical Encoder
|
|
|
Absolute Rotary Optical Encoder
|
|
|
Linear Optical Encoder
|
|
|
Electronic Compass Sensor
|
|
|
Seismometer
|
VIBRATION / ENVIRONMENTAL TEST SYSTEMS
|
|
Mechanical Shaker (centrifugal force based sinusoidal oscillator) based Vibration System (1200 Kgf to 25000 Kgf force)
|
|
|
Electro Dynamic Vibration Shaker System (1 Kgf to 2000 Kgf) Horizontal Slip Table,
vertical load support for EDV Shaker Systems
|
|
|
Bump / Shock / Impact Testing Machine
|
|
|
3D Impact Simulation Machines
|
|
|
Transport Simulation Machines
|
|
|
Centrifuge Machine ( 700 mm to 4.5 m radius , upto 50 g)
|
|
|
Variable speed DC motors for Mechanical Shakers (3 HP to 7 HP)
|
|
|
High efficiency `Class D' Power Amplifiers for EDV Shakers (1 to 15KVA)
|
|
|
Microprocessor (Z-80) based Vibration Controller / Programmer for EDV Shakers
|
|
|
PC + DSP based SINE Vibration Controller for EDV Shaker System
|
|
|
PC + DSP based Random Vibration Controller for EDV Systems
|
|
|
Mechanical Vibration Table
|
|
|
Motor Control Unit for Bump Testing Machine
|
|
|
Vibration Meter
|
MOTORS AND DRIVES
|
|
AC Induction Motor with DSP based Electronic Controller
|
|
|
Permanent Magnet Synchronous Motors with DSP based Sensorless Electronic Controller
|
|
|
Switched Reluctance Motor with DSP based Electronic Controller
|
|
|
Planetary Gear
Boxes for above motors
|
|
|
Gyro Motor
|
RECORDING INSTRUMENTS
|
|
DSP based Portable Digital Event Logging System
|
|
|
Master Slave Recorder
|
|
|
Seismic Recorder
|
|
|
Portable Seismic
Recorder
|
|
|
2 - Channel Table
Torque Recorder
|
|
|
Multichannel Galvanic Recorder For Satellite Tracking with Distance Mode Drive
|
|
|
4 - Channel
Recorder for Electro Logging
|
MISCELLANEOUS EQUIPMENTS / PRODUCTS
|
|
|
